Indoor Small Pixel Pitch Transparent Led Screen For Hire
In today's hectic world, captivating visuals have emerged as a pivotal tool to draw crowds, engage spectators, and craft unforgettable moments. With this trend in mind, we are thrilled to unveil our cutting-edge Indoor Transparent LED Screen for rent.
Send Inquiry
Product Description
1.Indoor Rental Screen Applications
Advertising
Science museum Experience Hall
Retail Shops
Media Facade
Showroom
Car Dealers
Supermarkets
Consumer Electronic Stores
Shopping Malls
Exhibition Construction
In today's hectic world, captivating visuals have emerged as a pivotal tool to draw crowds, engage spectators, and craft unforgettable moments. With this trend in mind, we are thrilled to unveil our cutting-edge Indoor Transparent LED Screen for rent.
This screen combines functionality, elegance, and adaptability, rendering it a versatile choice for diverse events and applications. Its high-definition display and transparent properties enable it to blend seamlessly into any indoor setting, while simultaneously drawing the gaze of onlookers.
The transparent design allows for a clear view of the backdrop, creating a visually arresting effect that enriches the overall atmosphere. Whether you're displaying your brand identity, broadcasting promotional content, or showcasing live events, our Indoor Transparent LED Screen ensures your message shines brightly.
One notable benefit is its adaptability. It can be quickly assembled and dismantled, making it a perfect fit for temporary events, exhibitions, and trade fairs. Our team of professionals will guide you from installation to operation, guaranteeing a smooth and efficient event experience.
Moreover, this screen boasts advanced technology that guarantees exceptional image clarity and reliability. Its high luminance and expansive viewing angle ensure your content remains vivid and impactful, regardless of lighting or viewing angle.
Apart from its technical prowess, this screen also exudes a sleek and contemporary design that complements any interior. Its lightweight and slim build allows it to fit into even the most cramped spaces, making your display a standout without compromising the overall aesthetic.
2.Product Features
Small module size: 500*125mm
Pixel Pitch: P3.91x7.82 and P7.82x7.82
Cabinet size (width×height):1000*500mm
Brightness:can be reach 5000nits
Refresh Rate:1920-3840HZ
Kg/Piece:6kg/Piece
 |
 |
3.Parameters
| P3.9x7.8 Indoor Rental Transparent LED Display | ||||||
| LED lamp parameter | ||||||
| NO. | Type | Brightness | View angle（Horizontal/Vertical） | Wavelength | Test Condition | |
| 1 |  |
Red LED | 30~60MCD | 110º±5º | 615-630nm | 25℃, 15mA |
| 2 | Green LED | 130~250MCD | 110º±5º | 515-535nm | 25℃, 8mA | |
| 3 | Blue LED | 15~380MCD | 110º±5º | 465-480nm | 25℃, 5mA | |
| LED pixel configuration | ||||||
| NO. | LED Type | Size |
Small module 500*125mm:
|
|||
| 1 | pixel configuration | 1R1G1B | ||||
| 2 | Pixel encapsulation | SMD1921 | ||||
| LED Cabinet Parameter | ||||||
| 1 | Pixel Pitch | 3.91x 7.82mm | ||||
| 2 | Scan method | 8 scan | ||||
| 3 | Module Resolution | 128dots×16dots | ||||
| 4 | Module dots | 2048 dots | ||||
| 5 | Cabinet size (width×height) | 1000*500mm | ||||
| 6 | Resolution ((dot/㎡) | 32768 dot/sqm | ||||
| 7 | Max. Power (W/㎡) | 800watts | ||||
| 8 | Ave. power (W/㎡) | 240 watts | ||||
| 9 | Module raw material | CNC Die-casting aluminium | ||||
| 10 | Brightness | ≥5000cd/㎡ | ||||
| 11 | View Angle | (H)140°，(V)140° | ||||
| 12 | Minimal Viewing Distance | ≥3M | ||||
| 13 | Gray Scale | 16bit | ||||
| 14 | Refresh Rate | 1920-3840HZ | ||||
| 15 | Repetition Frequency | 60HZ | ||||
| 16 | Input Voltage | AC 85-240V | ||||
| 17 | Power supply | PFC power supply,CE/UL approved | ||||
| 18 | Ghost cancellation circuit | Included | ||||
| 19 | Transparency | ≥70% | ||||
| 20 | Led lifespan | ≥100,000 hours | ||||
| 21 | IP Protection | IP30 | ||||
| 22 | Working temperature | ﹣40℃～40℃ | ||||
| 23 | Environment humidity | 15%～90% | ||||
| 24 | kg/Piece | 6kg/Piece | ||||
| 25 | Control system | Nova/Colorlight | ||||
| 26 | Installation way | Hanging (20pcs height max) /Standing | ||||
| 27 | Display connection port | DVI/HDMI/DP/NETCABLE | ||||
| P7.8x7.8 Indoor Rental Transparent LED Display | ||||||
| LED lamp parameter | ||||||
| NO. | Type | Brightness | View angle（Horizontal/Vertical） | Wavelength | Test Condition | |
| 1 | |
Red LED | 30~60MCD | 110º±5º | 615-630nm | 25℃, 15mA |
| 2 | Green LED | 130~250MCD | 110º±5º | 515-535nm | 25℃, 8mA | |
| 3 | Blue LED | 15~380MCD | 110º±5º | 465-480nm | 25℃, 5mA | |
| LED pixel configuration | ||||||
| NO. | LED Type | Size |
Small module 500*125mm:
|
|||
| 1 | pixel configuration | 1R1G1B | ||||
| 2 | Pixel encapsulation | SMD1921 | ||||
| LED Cabinet Parameter | ||||||
| 1 | Pixel Pitch | 7.82x 7.82mm | ||||
| 2 | Scan method | 4 scan | ||||
| 3 | Module Resolution | 64dots×16dots | ||||
| 4 | Module dots | 1024 dots | ||||
| 5 | Cabinet size (width×height) | 1000*500mm | ||||
| 6 | Resolution ((dot/㎡) | 16384 dot/sqm | ||||
| 7 | Max. Power (W/㎡) | 800watts | ||||
| 8 | Ave. power (W/㎡) | 240 watts | ||||
| 9 | Module raw material | CNC Die-casting aluminium | ||||
| 10 | Brightness | ≥5000cd/㎡ | ||||
| 11 | View Angle | (H)140°，(V)140° | ||||
| 12 | Minimal Viewing Distance | ≥3M | ||||
| 13 | Gray Scale | 16bit | ||||
| 14 | Refresh Rate | 1920-3840HZ | ||||
| 15 | Repetition Frequency | 60HZ | ||||
| 16 | Input Voltage | AC 85-240V | ||||
| 17 | Power supply | PFC power supply,CE/UL approved | ||||
| 18 | Ghost cancellation circuit | Included | ||||
| 19 | Transparency | ≥70% | ||||
| 20 | Led lifespan | ≥100,000 hours | ||||
| 21 | IP Protection | IP30 | ||||
| 22 | Working temperature | ﹣40℃～40℃ | ||||
| 23 | Environment humidity | 15%～90% | ||||
| 24 | kg/Piece | 6kg/Piece | ||||
| 25 | Control system | Nova/Colorlight | ||||
| 26 | Installation way | Hanging (20pcs height max) /Standing | ||||
| 27 | Display connection port | DVI/HDMI/DP/NETCABLE | ||||
